Atlas Standard Duty Revolving Centres
  • Atlas Standard Duty Revolving Centres

Atlas Standard Duty Revolving Centres

RM462.20
Tax excluded
ATL4881020K
Morse Taper
Quantity
Out-of-Stock


Standard Duty Revolving Centres

Manufactured from high alloy steel hardened and tempered then precision ground externally. Precision bearings are fitted as standard and the centres have a 60° point.

Maximum runout: 0.005mm.

Morse Taper Max RPM Radial Load(rpm) Axial Load(rpm) Weight
@100(kgf) @max(kgf) @100(kgf) @3000(kgf)
No.2 7000 200 50 250 50 0.50kg
No.3 6000 300 80 380 90 0.80kg
No.4 5000 800 220 900 270 2.30kg

IMAGE IS FOR ILLUSTRATION PURPOSES
